针数Number of contacts345锁紧方式Connector locking system螺...
|
针数 |
Number of contacts |
3 |
4 |
5 |
|
锁紧方式 |
Connector locking system |
螺纹式/ screw |
||
|
连接方式 |
Termination |
螺纹，浇铸电缆/ screw moulded on cable |
||
|
连接截面 |
Wire gauge |
螺纹 0.14-0.5mm 2 (AWG 26) /浇铸电缆 0.25mm 2 (AWG 24) |
||
|
电缆直径 |
Cable outlet |
螺纹 3.5-5mm /浇铸电缆 4.5mm |
||
|
防护等级 |
Degree of protection |
IP67 |
||
|
机械寿命 |
Mechanical operation |
>100 插拔周期/ >100 mating cycles |
||
|
最高工作温度 |
Upper temperature |
+ 80 ℃ |
||
|
最低工作温度 |
Lower temperature |
- 20 ℃ |
||
|
额定电压 |
Rated voltage |
60V |
30V |
|
|
额定冲击电压 |
Rated impulse voltage |
1000V |
800V |
|
|
污染等级 |
Pollution degree |
3 |
||
|
过电保护等级 |
Overvoltage categorie |
Ⅱ |
||
|
绝缘组别 |
Material group |
Ⅲ |
||
|
额定电流（40摄氏度） |
Rated current(40 ℃) |
4A |
||
|
触点电阻 |
Contact resistance |
≤3mΩ |
||
|
触点材料 |
Materila of contact |
CuZn( 黄铜/ brass) |
||
|
触点电镀材料 |
Contact plating |
Au( 金/ gold) |
||
|
插座材料 |
Materila of contact body |
PUR |
||
|
外壳材料 |
Materila of housing |
PUR |
||
